KEY BENEFITS
>Scalable synchrophasor measurements with up to 6 PMUs per IED reducing synchrophasor cost by up to 80%
>Real-time access to remote analog data, providing for advanced wide area applications and enhanced system security
>Exceeds the latest IEEE® C37.118 standard for PMU measurementdevices with a TVE of less than 1%, protection and metering classn synchrophasors and multi-cast IEC® 61850-90-5 support
>Uninterrupted synchrophasor measurements during fault anddisturbances, providing highly reliable capture of data for critical control functions and post-mortem analysis
>Three independent fiber or copper Ethernet ports for simultaneous/dedicated network connections with 1 microsecond time synchronization via LAN with IEEE 1588 support
>Simplified system integration with direct connection to JungleMUX SONET, TN1U SDH and TN1Ue SDH networks
>Increase network availability by reducing failover time to zero through IEC 62439-3 “PRP” support
>CyberSentry? provides high-end cyber security aligned to industry standards and services (NERC® CIP, AAA, Radius, RBAC, Syslog)
>Complete IEC 61850 Process Bus solution provides resource optimization and minimizes total P&C life cycle costs
APPLICATIONS
>Decrease blackouts by identifying network instabilities and taking fast preventative action
>Increase utilization of existing investments by identifying power transfer capability on existing lines
>Compliments existing protection and control by sharing power and utilization information with existing systems to enhance system security
>Facilitate contingency planning through continuous synchrophasor data collection and postmortem analysis
>Provides enhanced state estimation for SCADA to optimize system-wide load shedding and remedial action schemes
>Mitigate system critical conditions such as power system dampening and loss of synchronism through the use of enhanced automated control to reduce outages
