KEY BENEFITS
>Cost-effective, five zone quad or mho, phase and ground distance protection
>Programmable logic for building customized pilot schemes
>Application flexibility: multiple I/O options, programmable logic (FlexLogic?)
>Simplified teleprotection interfaces with direct I/O communications hardware for transfer trip and custom-built pilot-aided distance schemes
>Three independent fiber or copper Ethernet ports for simultaneous/ dedicated network connections with advanced 1 microsecond time synchronization via LAN with IEEE® 1588 support
>Reduced relay-to-relay wiring and associated installation costs through high-speed inter-relay communications
>Embedded IEC® 61850 protocol
>Increase network availability by reducing failover time to zero through IEC 62439-3 “PRP” support
>CyberSentry? provides high-end cyber security aligned to industry standards and services (NERC® CIP, AAA, Radius, RBAC, Syslog)
>Complete IEC 61850 Process Bus solution provides resource optimization and minimizes total P&C life cycle costs
APPLICATIONS
>Overhead sub-transmission lines and underground cables including series compensated lines
>Circuits requiring three-pole autoreclosing and independent synchrocheck supervision
>Circuits with in-zone power transformers
>Secure application with Capacitively-Coupled Voltage Transformers (CCVTs)
>Backup protection for generators, transformers and reactors
